Installing the Motherboard
Refer to the illustration below for proper installation:
This motherboard does not support the “Hot-Plug” function.
1
Attach either cable end to the connector on the motherboard.
2
Atta
ch the other cable end to the SA
T
A
hard drive.
3
Atta
ch the SA
T
A
power cable to the SA
T
A
hard drive a
nd connect the
other end to the power supply
.
