Normal mode will appear on the screen. The Normal mode will
also be shown on the screen under conditions a & b above.
d. Hard disk drives with less than 528MB total capacity must be set
to Normal mode when combined with either old BIOS versions or
the Award BIOS.
LBA and Large modes are new specifications which may not be fully
supported by all operating systems. An example of which is the
current version of UNIX System (R3.2.4) which is still unable to
support the LBA function. Therefore, determine the specifications of
your hard disk drive and operating system before selecting the drive's
mode.
#%'( "! !!
!!
ROM PCI/ISA BIOS (P5VX-Be)
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
HARD DISKS TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE
−
Primary Master :
Select Primary Master Option (N=Skip) : N
OPTIONS SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE
1 0 0 0 0 0 0 NORMAL
Note: Some OSes (like SCO-UNIX) must use "NORMAL" for installation
Esc : Skip
