CPL8-CPM-4-8-10-I-0416
Page 10
800-638-3326 • edcoinc.com • sales@edcoinc.com
EQUIPMENT DEVELOPMENT CO., INC.
To remove or replace drum assembly on the CPM-4 remove
the two (2) bolts securing the drum cover plate in the photo
on the left.
Next remove the socket head screw as shown in the photo
on the left.
Slide the drum out as shown in the photo on the left.
Reverse procedure to reassemble.
CPM-4 DRUM REMOVAL / REPLACEMENT
CPM-4 and CPM-8 EDGER ATTACHMENT
