Status Indications Output forward and reverse power and combiner temperature.
Output forward power, temperature and current of any selected Amplifier
module.
Power Supplies, Cooling fans and (when connected) Drives’ status.
Red/green pass/fail led indicators on all modules.
Dimensions Height :- 7U
Width :- to fit standard 19in rack.
Depth :- to fit standard 600mm deep rack.
Environmental Ambient Temperature (operating) : -5 to +50 deg.C
Ambient Temperature (storage) : -20 to +70 deg.C
Relative Humidity (operating) : Less than or equal to 90%, non condensing
with the transmitter at a higher temperature than the ambient.
Altitude (operating) : Up to 3000 metres a.s.l.
Power Supply
-01 , -02, -03 and –
04 single mains
supply variants
Single phase input.
90 to 260V AC, 47- 63Hz.
Apparent power factor 98%.
Efficiency 88% (Power Supply units only)
Supply current at 230V AC typically :-
4A (with 500W RF output)
Supply current at 115V AC typically :-
8A (with 500W RF output)
Typical overall efficiency 55% at above power levels (AC in to RF out)
Power Supply
-05, –06, -07 and
–08 dual mains
supply variants
Each Single phase input.
90 to 260V AC, 47- 63Hz.
Apparent power factor 98%.
Efficiency 88% (Power Supply units only)
Supply current at 230V AC typically :-
2A (with 500W RF output and both mains supplies present)
4A (with 500W RF output and only one mains supply present)
Supply current at 115V AC typically :-
4A (with 500W RF output and both mains supplies present)
8A (with 500W RF output and only one mains supply present)
Typical overall efficiency 55% at above power levels (AC in to RF out)
