1.2 : VARIANTS AND OPTIONS
The main variants and their constituent modules and units are as follows :-
(NOTE that the variant type is identified on the serial number plate – the initial display on the E2023
Controller will display S79005-1 or –2 which only indicates the number of power supply units fitted and
not the variant)
Amplifier
Modules
Power
Supplies
Transmitter
Auto. Cont.
Splitter and
Drive C/O
Combiner
Unit
S79005-01
Single PSU
Single Mains
Input
2 off
E2021-XX
Single
E2088-01
Single
E2023-01, 03
or
E2023-02, 04 (/T
Option)
Single
E2026-05
Single
E2029-01
S79005-02
Dual PSUs
Single Mains
Input
2 off
E2021-XX
2 off
E2088-01
Single
E2023-01, 03
or
E2023-02, 04 (/T
Option)
Single
E2026-05
Single
E2029-01
S79005-03
Single PSU
Single Mains
Input
2 off
E2021-XX
Single
E2322-01
Single
E2023-01, 03
or
E2023-02, 04 (/T
Option)
Single
E2026-05
Single
E2029-01
S79005-04
Dual PSUs
Single Mains
Input
2 off
E2021-XX
2 off
E2322-01
Single
E2023-01, 03
or
E2023-02, 04 (/T
Option)
Single
E2026-05
Single
E2029-01
S79005-05
Dual PSUs
Dual Mains
Input
2 off
E2021-XX
2 off
E2088-01
Single
E2023-01, 03
or
E2023-02, 04 (/T
Option)
Single
E2026-05
Single
E2029-01
S79005-06
Dual PSUs
Dual mains
Input
2 off
E2021-XX
2 off
E2322-01
Single
E2023-01, 03
or
E2023-02, 04 (/T
Option)
Single
E2026-05
Single
E2029-01
S79005-07
Dual PSUs
Dual Mains
Input
48V Output
2 off
E2021-XX
2 off
E2088-01
Single
E2023-01, 03
or
E2023-02, 04 (/T
Option)
Single
E2026-05
Single
E2029-01
S79005-08
Dual PSUs
Dual mains
Input
48V Output
2 off
E2021-XX
2 off
E2322-01
Single
E2023-01, 03
or
E2023-02, 04 (/T
Option)
Single
E2026-05
Single
E2029-01
The option (identified by letter suffix) are as follows :-
/T Fitted with TCP/IP Remote Control (on E2023-02 or -04)
Example is as follows :-
S79005-05/T Standard 500W (with dual E2088’s, dual mains supply input and TCP
Remote Control)
