Typical
Quantity
Description Function
1 N Type coaxial free plug. For connection to lead from Antenna or RF
output load.
Length
as req’d
Low loss 50Ω RF coaxial cable, rated
in excess of Transmitter output
power at maximum ambient
temperature.
RF output lead.
1 - 3
TNC 50Ω RF coaxial free plug(s).
For connection to leads from Exciter/Drive(s)
and their dummy load.
Length
as req’d
Low loss 50Ω RF coaxial cable, rated
in excess of Exciter/Drive output
power at maximum ambient
temperature.
RF input and dummy load leads.
1
Coaxial, 87.5 – 108MHz, 50Ω load
with suitable free connector, rated in
excess of Exciter/Drive output power
at maximum ambient temperature.
Exciter/Drives’ dummy load.
1 2 Way, 10A, 5.08mm pitch screw
terminal block (c/w wire shorting link).
(e.g. Weidmuller BL5.08/2)
External safety interlock connector (wire shorting
link is removed when connector is wired to
external safety circuits).
1 - 2 9 Way D plugs c/w covers. For connection to leads from control/monitor
inputs of Exciter/Drive(s).
1 - 2 9 Way D sockets c/w covers. For connection to parallel and serial RS232
remote control/monitor links.
1 15 Way D plug c/w cover. For connection to additional control/monitor
input links.
Length
as req’d
Multi-core screened cable (number of
cores as required).
Control/monitor leads.
Length
as req’d
Heavy gauge grounding wire/strap. For safety earth lead.
1-2 IEC 6A free plug to free socket mains
leads (1 metre, 3 core each
0.75mm
2
, EPR insulated, HOFR
sheathed for high temperatures).
For fused and switched mains supply
connections to Exciter/Drive(s).
1
(-07 and
–08
variants)
DC supply connector/lead
(Neutrik ‘Speakon’ NL2FC free
connector plus 7x0.2mm (0.22mm
2
)
strand red (+) and black (-) PVC
insulated cable)
For fused and switched +48V DC connection to
ancillary equipment.
8 Screws c/w plastic cup washers and
rack caged nuts.
For fixing Transmitter into 19 inch rack.
2 Side support ‘L’ brackets c/w fixing
screws and washers.
For extra support to carry the Transmitter’s
weight in the rack.
3 500mA (F) Fuses (for smd holders,
‘Littelfuse’ R451.500)
For protection of control circuits within E2021
Amplifiers and E2026 Drive Changeover/Output
Monitor Unit.
2 16A (T) HBC 5x32mm (¼ x1¼ in)
Fuses
For protection of internal dc supply leads to and
high current circuitry within E2021 Amplifiers.
3/4 6.3A (T) HBC 5x20mm Fuses For protection of internal low current dc supply
leads and of mains supply leads and circuitry
intended for connection to Exciter/Drives(s).
1
(-07 and
–08
variants)
1A (T) HBC 5x20mm Fuse For protection of +48V DC supply to ancillary
equipment.
