Print Date 08/04/14 Page 25 of 34 S79005-00MA-05
Remote Input Status Requests
(third byte sent from controller after ? command)
Title Function Hex ASCII
Op_Stat Revert output status 30 0
Amp1_Stat Revert amplifier 1 status 31 1
Amp2_Stat Revert amplifier 2 status 32 2
Amp3_Stat Revert amplifier 3 status 33 3
Amp4_Stat Revert amplifier 4 status 34 4
Amp5_Stat Revert amplifier 5 status 35 5
Amp6_Stat Revert amplifier 6 status 36 6
Amp7_Stat Revert amplifier 7 status 37 7
Amp8_Stat Revert amplifier 8 status 38 8
Amp9_Stat Revert amplifier 9 status 39 9
Amp10_Stat Revert amplifier 10 status 3A :
Amp11_Stat Revert amplifier 11 status 3B ;
Amp12_Stat Revert amplifier 12 status 3C <
Amp13_Stat Revert amplifier 13 status 3D =
Amp14_Stat Revert amplifier 14 status 3E >
Amp15_Stat Revert amplifier 15 status 3F ?
Amp16_Stat Revert amplifier 16 status 40 @
Amp17_Stat Revert amplifier 17 status 41 A
Amp18_Stat Revert amplifier 18 status 42 C
Amp19_Stat Revert amplifier 19 status 43 B
Amp20_Stat Revert amplifier 20 status 44 D
Amp21_Stat Revert amplifier 21 status 45 E
Amp22_Stat Revert amplifier 22 status 46 F
Amp23_Stat Revert amplifier 23 status 47 G
Amp24_Stat Revert amplifier 24 status 48 H
Amp25_Stat Revert amplifier 25 status 49 I
Amp26_Stat Revert amplifier 26 status 4A J
Amp27_Stat Revert amplifier 27 status 4B K
Amp28_Stat Revert amplifier 28 status 4C L
Amp29_Stat Revert amplifier 29 status 4D M
Amp30_Stat Revert amplifier 30 status 4E N
Amp31_Stat Revert amplifier 31 status 4F O
Amp32_Stat Revert amplifier 32 status 50 P
Amp33_Stat Revert amplifier 33 status 51 Q
Amp34_Stat Revert amplifier 34 status 52 R
Amp35_Stat Revert amplifier 35 status 53 S
Amp36_Stat Revert amplifier 36 status 54 T
Amp37_Stat Revert amplifier 37 status 55 U
Amp38_Stat Revert amplifier 38 status 56 V
Amp39_Stat Revert amplifier 39 status 57 W
Amp40_Stat Revert amplifier 40 status 58 X
Sys_Stat Revert system status 59 Y
Dri_Stat Revert drive status 5A Z
Remote Input Controls
(third byte sent from controller after % & , + commands)
Title Function Hex ASCII
A_Drive Set auto drive to A 41 A
B_Drive Set auto drive to B 42 B
Passive Set drive mode to passive 50 P
Active Set drive mode to active/unmuted 55 U
Pwr_Hi Set Tx power to high 48 H
Pwr_Lo Set Tx power to low 4C L
Mute Set Tx to mute 4D M
Unmute Set Tx to start/unmute 53 S
