Eden Birdlip - Glazing Instructions; Maintenance Advice

Birdlip





2

EdenGreenhousesCustomerHelpline+44(0)1242676625


Base
Theintegralbasemustbe100%levelandsquare,thelattercanbedoneby
checkingthe2diagonalsareequal.Ifitisnotsquaretheglazingwillnotfit.






Construction













Foreachsection,laytheprofilesoutonthegroundinthesamewayaspicturedin
themaindiagram.Assembleintheorderofthepictures.
M6x10bolts/nuts(parts50and51)arenotlistedonindividualpartslistsasthey
areusedineachsection.
Thefollowingsymbolsshowwhetheranillustrationisviewedfrominsideor
outsidethegreenhouse:

Viewedfromtheinside
    Viewedfromtheoutside
(Whitebackground)    (Blackbackground)



Takenoteofwhereyouwillneedtoslideextraboltsintothechannelsforfixing
horizontalbars,bracingorroofventsillsasperexample
picturetotheright.
Fastentheprofilestogetherbyslidingthesquareheaded
boltsinto
thechanneloftheprofileandattachtotheholein
thecorrespondingbar.Donottightenthenutscompletely
untilthecompletedframeissquare.NOTETHATALLCONNECTINGPROFILES
MUSTBEFLUSHANDTIGHTTOGETHERTOENSURETHATLEAKINGISKEPTTOA
MINIMUM.
Thedoorhasa
zerothreshold™.Component19atthebaseofthedooronthe
frontgable(SECTION2FRONTGABLE)isusedasabracetogaugethedistance
betweenthetwocomponents18andtomakeconstructioneasier.Thiswillthen
beremovedinSECTION10FINISHING.

Glazing
Glazingmustbecompletedinoneoperation.Fittherubberglazinggaskettoall
theprofilesasshowninSECTION8,LOCATINGbeforefittingtheglass.Notethere
are3differentplansforglazing:horticulturalglass,toughenedglassor
polycarbonate.Glazetherooffirst,thensidesandgableends.Glazeroofvents
beforeslidinginfromTHEENDoftheridgebarasshowninSECTION10
FINISHING.GlazethedoorbeforehangingasshowninSECTION7DOOR.

FinishingTouches
Fitallplasticparts,i.e.RidgeCap,GutterEndCapsandIntegralBaseCornerCaps
bypushingintoplaceas
inSECTION10,FINISHING.
Note:FitIntegralBaseCornerCapsbeforesecuringdownthegreenhouse.

Maintenance
 Thedoorslidersandlockwillneedtobelubricatedapproximatelyevery6
monthswithanOUTDOORlubricanttoensuresmoothoperation.
 Thegutterswillneedtoberegularlyclearedof
leavesanddebristoensure
efficientdrainage.
 Replaceallbrokenpanesofglassimmediately,failuretodosomaycause
structuralfailure.
 Removesnowloadsfromtheroof.
Introduction

Introduction

1

1

COMPONENTSLIST
SECTION0FOUNDATION
SECTION1REARGABLE
SECTION2FRONTGABLE
SECTION3SIDES
SECTION4ASSEMBLE
SECTION5ROOF
SECTION6WINDOWS
SECTION7DOOR
SECTION8LOCATING
SECTION9GLAZING
SECTION10FINISHING
