IMPORTANT
a
b
Do not remove the spe-
cifications plate, it con-
tains vital information.
4
CONNECTING TO THE ELECTRICITY SUPPLY
Consult the specifications
plate located on the port-hole
before connecting to the elec-
tricity supply. Make sure that
the voltage supplied to the
plug corresponds with that
indicated on the plate.
IMPORTANT
It is very important that the washing machine be connected to a good-quality earth installa-
tion. The electrical installation, plug, socket, fuses or automatic switch and meter must be
designed to withstand the maximum power setting indicated on the specifications plate.
If the power cord is damaged, it must be replaced by one with the same reference number,
only available from an authorised service centre. On built-in washing machines, the mains
plug must be accessible after installation.
It is important that the elbow of the drainpipe is well fitted into the stand pipe to avoid any
risk of it falling out and causing flooding. If your washing machine is equipped with a hot
water inlet, connect one end of the red threaded pipe to the hot water tap and the other to
the electrovalve with the red filter. The washing machine is to be connected to the water
supply network using the new supply pipes provided with the appliance. The old water
supply pipes are not to be used. For correct functioning of the washing machine, the water
network pressure must be between 0.05 and 1 MPa (0.5 - 10 Kgrf/cm
2
).
