EDGETEC SYSTEMS PTY LTD Part # 9-2100 MAY 2012
Your spa bath pump should be installed on a well drained location or
on a suitable drain tray to avoid water damage to property should any
leaks occur from pipe work, connections or normal wear.
Air Tube Connection “Auto-Heat & Xtra- Heat Models” (refer diagram 3)
1. Supplied with your spa pump is a 4 metre roll of 3mm clear air tube, fit one
end of the air tube to the air button (supplied with the spa bath) on the spa
bath.
2. Uncoil the air tube so that you can connect it to the air switch located on the
pump (refer diagram 3) at the rear of the pump motor on the capacitor
cover.
3. Cut off excess tube and ensure that the tube is not kinked, do not wrap or
loop excess tube around frame work of the bath or pipe work as this may
cause the air button not to operate correctly.
Touch Pad Cable Connection “Sensa-Touch Model” (refer diagram 5)
1. Supplied on your spa bath is the Sensa Touch Pad, connected to the touch
pad will be a 4 metre data cable.
2. Uncoil the data cable and you will see that one end is already connected to
the touch pad on the spa bath.
3. Connect the other end to the pump as per diagram 5, ensuring that the data
cable connection clip is being inserted correctly. Push the clip in until you
hear it “click” into the fixed position.
4. Push the protective rubber cap that is on the cable over the circular housing
(refer diagram 5) to protect the touch pad cable connection. Failure to do
this may void your warranty.
5. When power is activated there will be a “Green” indicator light activated on
the touch pad to show that the connection is fitted correctly from the pump to
the touch pad.
Start Up
1. Fill the spa bath to approximately 50mm above the spa jets, check the pump
and pipe connection for any leaks.
2. Ensure that the pump power outlet is switched to the “on“ position.
3. Auto-Heat & Xtra-Heat pumps. Press the air button on the spa bath, the pump
will start and purge the air from the system and your spa will start to operate.
To stop the spa, simply press the air button again.
4. Sensa-Touch pump. Press the pump symbol on the touch pad, the pump will
start and purge the air from the system and your spa will start to operate. To
stop the spa, simply press the pump symbol on the touch pad.
5. Spa-Key. Press the pump symbol on the hand set, the pump will start and
purge the air from the system and your spa will start to operate. To stop the
spa, simply press the pump symbol on the hand set.
6. If the pump fails to prime you may have an air lock, please refer to activating
air bleed.
Never run your spa pump without water as this can cause
serious damage to the mechanical seal which may cause the
spa pump to leak. Running the pump without water will void
your warranty.
