Step 2 – connect to your 4200
The 4200 is shipped with a pre-configured IP address on its LAN port of 192.168.1.1.
To connect to the 4200, do the following:
• Configure your PCs ethernet adapter to use an IP address of 192.168.1.2
and a subnet mask of 255.255.255.0. (If using a LAN switch then the
switch must support 100Mbps full duplex).
• Launch a Web browser on the PC and enter the URL 192.168.1.1.
• Press Return. The initial 4200 main configuration menu appears.
• Select the Network link - enter the username "root" and the password
"default."
• Continue to configure the LAN and WAN ports and the rest of the
appliance using the information in Step 3 below as a guideline.
