EDI CMUip-2212-HV User Manual

CMUip-2212 Cabinet Monitor Unit
Operations Manual
Eberle Design Inc. Page 14
the solid yellow arrow clearance while the Opposing Through channel is still showing a
green ball.
When the FYA Yellow Trap Conflict condition is detected, the CMUip-2212 will enter the
fault mode, transfer the OUTPUT relay contacts to the Fault position, and display the
“CONFtrap” fault status screen. The CMUip-2212 will remain in the fault mode until the unit
is reset by the RESET button.

EDI CMUip-2212-HV Specifications

General

Brand	EDI
Model	CMUip-2212-HV
Category	Controller
Language	English
