EDI CMUip-2212-HV User Manual

CMUip-2212 Cabinet Monitor Unit
Operations Manual
Eberle Design Inc. Page 21
Section 5
SPECIFICATIONS
5.1 ELECTRICAL
5.1.1 CMU-2212-HV
Power Requirements
Operating Line Voltage ................................................................................... 75 to 135 Vac
Operating Line Frequency .................................................................................... 60 ± 3 Hz
Power Consumption .............................................................................. 10 Watts Maximum
AC Field Signals
LEDguard Field Signal High Levels
Active ................................................................................. greater than 70 Vrms
Not Active ................................................................................ less than 50 Vrms
LEDguard Field Signal Low Levels
Active ................................................................................. greater than 25 Vrms
Not Active ................................................................................ less than 15 Vrms
AC Control Monitors
MC Secondary Status
Active ........................................................................................ greater than 83 Vrms
Not Active ...................................................................................... less than 77 Vrms
DC Control Monitors
Local Flash Status, MC Coil Status, FTR Coil Drive, CB Trip Status
Active ........................................................................................... greater than 44 Vdc
Not Active ......................................................................................... less than 42 Vdc
Front / Rear Door Switch
Active ........................................................................................... greater than 13 Vdc
Not Active ......................................................................................... less than 11 Vdc
Mains Power Fail Monitor
HV+ Mains Restore ....................................................................... greater than 87 ± 2 Vrms
HV+ Mains Dropout ............................................................................ less than 82 ± 2 Vrms
DC Voltage Monitors
+48 Volt Monitor
Active ........................................................................................... greater than 46 Vdc
Not Active ......................................................................................... less than 44 Vdc
+24 Volt Monitor
Active ........................................................................................... greater than 22 Vdc
Not Active ......................................................................................... less than 18 Vdc
+12 Volt Monitor
Active ........................................................................................... greater than 11 Vdc
Not Active .......................................................................................... less than 9 Vdc
Logic Inputs
External Test Reset, Serial Bus #1 Disable, Address 0, Address 1
Not Active (False) ........................................................................ greater than 16 Vdc
Active (True) ...................................................................................... less than 8 Vdc
CMU Temperature
Accuracy ..................................................................................................................... ± 6
o
C
