CONNECTING
Sound Card
R
1
2
e
3 Playing the audio device
Connecting
Connect the satellite speakers 3.5 Stereo Earphone Plug to the output port on the back panel of the Subwoofer.
Connecting the Audio device
Us 3.5 Stereo Earphone Plug with Wire- Controller, connect the Audio Device (Such as the computer
Sound Card, LINE-OUT,SPK-OUT).
Plug the AC power plug into the wall outlet and turn on the power switch.Now your speaker system is ready for
use. Adjust the volume control , then you can enjoy the music.
Operating
SPECIFICATIONS:
L
Total Power Output :
Input Impedance:
Input Sensitive:
Bass Unit:
Tweeter Unit:
Frequency Response:
Dimension(Subwoofer):
Dimension(Satellite):
Gross Weight:
RMS 2WX2+6W
10K Ohm
400 mV
4 Aluminum coil, 4 Ohm
Paper coil, 4 Ohm
58 Hz ~ 20 KHz
125(W) x 180(H) x 211(D)mm
80(W) x 131(H) x 105(D)mm
About 2.6 Kg
2 3/4
Connected
with AC power
