4
English
Illustration
1. Volume dial/Input selection
Press to switch amongst Line in 1→Line in 2→Optical→
Coaxial→Bluetooth input
Press and hold to disconnect Bluetooth in Bluetooth input
2. Treble control
3. Bass control
4. Power switch
5. Power cable
6. Line in input
7. Optical input
8. Coaxial input
9. Connect to passive speaker
10. Connect to active speaker
11. Indicator light
Red: Optical/coaxial input
Green: Line in input
Blue: Bluetooth input
⑦
⑥
⑧
⑨
⑩ ⑪
②
①
③
④
⑤
