MU 22N
7
1 TECHNICAL FEATURES
1.01 HYDRAULIC, MECHANICAL AND ELECTRICAL SPECIFICATIONS
Maximum cutting size and characteristics of material [ mm
and daN/mm2 ]
Ø22 mm / R=65 daN/mm²
Maximum output force from rod [ t ] 24
Maximum operating pressure [ bar ] 580
Dimensions: Length X Width X Height [ mm ] 402 X 145 X 236
Weight [ kg ] 13.3
Guaranteed no-load LwA sound level (CEI EN 60745-1
and CEI EN 60745-2-8) [ dB ] 101
No-load operator Lpa (CEI EN 60745-1 and CEI EN
60745-2-8) [ dB ] 90
Vibrations when cutting diam. 22 mm rod (CEI EN 60745-1
and EN ISO 5349)
2.12 m/s²
Input voltage [ V ] 230
Frequency [ Hz ] 50
Electrical power [ W ] 1400
Input current [A] 6.8
Insulation class II
RPM 14000
