INSTALLER
INDICATIVE DRAWINGS, NOT ALWAYS REFERRING TO THE SPECIFIC MODEL.
FITTING OF THE CERAMIC COVER PELLET
Take the ceramic (C2) put it close to the open cover
pellet fix it by hand with the 4 screws (V1).
FITTING OF THE FRONT PANEL (F)
Fix by hand the composant A to the ceramic
F with 4 screws . THen fix it together to the
stove.
F A
(C2)
(V1)
(V1)
(V1)
(V2)
FROM THE REAR
FROM THE REAR
NOTE
BE CAREFULL TO PUT AS SHOWED HERE
