6
ENGLISH
EDILKAMIN s.p.a. reserves the right to modify the product without notification in the inte-
rests of improvement.
TECHNICAL CHARACTERISTICS in accordance with EN 14785 The data shown below refers to the
actual installation and use and was taken during the certification phase by a notified body under the conditions
specified by the standard.
MYRNA
MYRNA Q
Nominal power Reduced power
Available power 10 3,5 kW
Yield 91,4 94,7 %
CO emissions at 13% O
2
0,0019 0,0012 %
Fumes temperature 136 75 °C
Fuel consumption * 0,8 2,3 kg/h
Tank capacity 25 kg
Draw 12 11 Pa
Autonomy 11 31 ore
Heatable volume ** 260 m
3
Fume duct diameter 80 mm
Air intake duct diameter 40 mm
Weight including packaging 160 kg
Energy efficiency class according to UE 2015-
1186 regulation (Class A++/G)
A+
TECHNICAL DATA FOR SIZING THE FLUE which must in any case satisfy the requirements in this sheet
and the installation instructions for the product.
Nominal power Reduced power
Fumes temperature at smoke outlet 163 90 °C
Minimum draw 0,01 Pa
Fumes flow rate 7,3 3,7 g/s
*A calorific value of 4.8 kW/Kg has been used to calculate consumption.
** The heatable volume is calculated based on the assumption of a heating demand of 33 Kcal/m³ hour.
ELECTRICAL SPECIFICATIONS
Power supply 230 Vac +/- 10% 50 Hz
Nominal power absorbed 126 W
Reduced power absorbed 23 W
Power absorbed in stand by 3 W
Power absorption during ignition 365 W
Remote control frequency (provided) 2,4 GHz
Protection Fusibile 4 AT, 250 Vac 5x20
TECHNICAL DATA
USER/INSTALLER
