Edimax 16 Port Nway Fast Ethernet PoE Web Smart Switch Specifications

Specification
Standards
IEEE 802.3af Power over Ethernet
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100BaseTX Fast Ethernet
ANSI / IEEE 802.3 NWay auto-negotiation
IEEE 802.3x Flow Control in full duplex
Collision / Carrier sense based backpressure in half duplex
IEEE 802.1p QoS
IEEE 802.1Q VLAN Tag
Features
Number of Ports: 16 PoE ports 10/100BaseT/T(X)
MAC Address: 4K
Buffer Memory: 156KB
Transmission Method: Store and Forward
Smart Features
Port Security Filter:
• TCP/UDP port based
• MAC Address based
• IP Address based
VLAN Setting:
• Port Based VLAN
• Tag Based VLAN ( 20 entries )
• VLAN ID (Up to 4094K )
QoS:
 Priority ( Port Based / TOS / Diffserv /DSCP/IPv4/ IPv6)
 Class of Service Configuration
 TCP/UDP Port Based
Management:
 Password-protected Access,
 On /Off PoE Port Settings,
 Web-base Management,
 Graphic User Interface
 Bandwidth Control
 Broadcast Storm Control
 Port Mirroring
 Port Configuration
 Programmable aging timer
 IGMP Snooping
 Trunk ( 4 Ports per Group, 2 Group per Device )
 Provide DHCP Client
 Firmware Update ( Web Base / TFTP )
Filtering/Forwarding Rates
100Mbps port - 148,800pps
10Mbps port - 14,880pps
Transmission Media
10BaseT Cat. 3, 4, 5 UTP/STP
100BaseTX Cat. 5 UTP/STP
LED Indicators
Per Port: Link/Act, PoE Act/Status
Per Unit: Power
Power Input
100~240V/AC, 50~60Hz
Power Output
48V/DC Per Port Output – 15.4 W Max Per Port
16 Ports at Full 15.4 W Output Supported
Power Consumption
260 Watts (Max)
Dimensions
440 × 220 × 42(L x W x H)
Weight
3.8 kg
Operating Temperature
0 to 60℃
Storage Temperature
-20 to 90℃
Humidity
10 to 90% RH (non-condensing)
Certifications
FCC Class A, CE
