Edimax EN-9230TX-32 Quick Install Guide

3. Technical Specification
Topology Star
Connector RJ-45
Standard
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-TX
Transmission Rate
10Mbps/20Mbps
100Mbps/200Mbps
1000Mbps/2000Mbps
Hardware Required IBM compatible PC with available PCI slot
IRQ & I/O Address Assigned by system
Drivers
Windows 98/98SE/Me/NT/ 2000/XP,
Netware Server 4.x/5.x/6.x, Netware ODI for
Linux, Unix, MAC OSX 10.2.x/10.3DOS,
LED Link / Activity
Dimension 120 x 40 mm
Temperature 32~131°F (0-55° C)
Humidity 10~95% (Non-condensing)
Certification FCC Class B, CE Mark, C-tick, VCCI
4. Hardware Installation
To insert the network adapter into your PC, follow the steps as
below:
1. Turn off the computer and remove its cover.
2. Insert the adapter into a PCI slot.
3. Secure this adapter to the rear of the computer Chassis and put
back the computer covers.
4. Connect the adapter to the network using twisted-pair cable.
