Edimax ET-913 - LED Indicators; LED Functionality; Technical Specifications; Ordering Information

4. LED Description
5. Technical Specifications
Standards : IEEE 802.3z, 802.3ab
Interface: 1 X RJ45 connector
1 X SC Duplex connector or
1 X SC Simplex connector (W2)
Operation LED: Power, FDX,
TP Link, FO Link, TP ACT, FO ACT
Power: I/P AC 100-240V
O/P DC 5V, 1.6A
Power Consumption:
5W
Weight: 300g (Net Weight)
Dimensions: 26 X 71 X 97 mm
Temperature : Operating: 0 ~ 50
o
C
Storage: -20 ~ 60
o
C
Humidity:
5% ~ 90% RH
Emission:
Electrical: UL, CSA
EMI: FCC Class A, CE
Media
TP EIA/TIA-568 Cat 5, 100M
Fiber 50/125, 62.5/125um multimode fiber
9/125, 10/125um single-mode fiber
Ordering Information,
Multi-mode
ET-913MSC: SC/850nm/550m
Single-mode
ET-913SSC1: SC/1310nm/10Km
ET-913SSC2: SC/1310nm/20Km
ET-913SSC3: SC/1310nm/30Km
ET-913SSC6: SC/1550nm DFB/60Km
Media Converter-G
1000Base-T To 1000Base-SX/LX
Media Converter
ET- 913 Series
ET-913MSC
ET-913SSC1
ET-913SSC2
ET-913SSC3
ET-913SSC6
User’s Guide
V 1.0
LED Color Function
PWR Green Lit when power is available
TP/Link Green Lit when TP cable connection with
remote device is good
FO/Link Green
Lit when Fiber cable connection
with remote device is good
TP ACT Green Lit when TP is activity
FO ACT Green Lit when Fiber is activity
FDX Green Lit when TP port Full Duplex Mode is
enabled
Media Converter-G
