48
Getting connected and installing drivers (Macintosh)
■ Installing the SD-20 driver (FreeMIDI)
Use the following procedure to install the SD-20 driver. The included SD-20
FreeMIDI driver is an add-on module for using the SD-20 with FreeMIDI. In
order to use it, FreeMIDI must be installed on the hard disk from which
you started up.
* Disconnect the SD-20 from the Macintosh before beginning the installation.
1
Exit all currently running software (applications).
If you are using a virus checker or similar software, be sure to exit this as well.
2
Prepare the CD-ROM.
Insert the CD-ROM into the CD-ROM drive.
3
Double-click the SD-20 FM USB Driver-E icon (found in the Driver -
FreeMIDI - USB Connection folder of the CD-ROM) to start up the installer.
4
Verify the installation location, and click [Install].
fig.3-2_40
5
If a message like the following is
displayed, click [Continue].
The other currently running
applications will exit, and
installation will continue.
6
A dialog box will indicate Installation completed. Click [Restart] to restart
your Macintosh.
7
Use the USB cable to connect the SD-20 to your computer.
8
Switch ON the SD-20’s Power switch.
FreeMIDI settings
1
From the CD-ROM, copy the Driver - FreeMIDI Driver - Settings folder
onto the hard disk of your Macintosh.
2
Open the FreeMIDI Applications folder from the location into which you
installed FreeMIDI, and double-click the FreeMIDI Setup 1.45 icon to start it up.
3
When “OMS is installed on this computer...” appears, click [FreeMIDI].
This unit is equipped with
a protection circuit. A brief
interval (a few seconds)
after power up is required
efore the unit will operate
normally.
