Page #20 background imageLoading...
Page #20 background image
20
AC Current/DC Current + AC Current
NNootteess::
above accuracies can be guaranteed within 10% to 100% of the full range.
DC Current
NNootteess::
above accuracies can be guaranteed within the full range.
Resistance
NNootteess::
above accuracies can be guaranteed within the full range.
RANGE RESOLUTION ACCURACY VOLTAGE
40Hz~1KHz 1KHz~10KHz 10KHz~20KHz DROP
500µA 0.01µA ± (0.75% + 20) ± (1% + 20) ± (2% + 20)
102µV/µA
5000µA 0.1µA ± (0.75% + 10) ± (1% + 10) ± (2% + 10)
50mA 1µA ± (0.75% + 20) ± (1% + 20) ± (2% + 20)
1.5mV/mA
500mA 10µA ± (0.75% + 10) ± (1% + 10) ± (2% + 10)
5A 0.1mA ± (0.75% + 20) ± (1.5% + 20) ± (5% + 20)
30mV/A
10A 1mA ± (1% + 10) ± (1.5% + 10) Unspecified
RANGE RESOLUTION ACCURACY VOLTAGE DROP
500
µ
A 0.01
µ
A ± (0.15% + 15)
102µV/µA
5000
µ
A 0.1
µ
A ± (0.15% + 10)
50mA 1
µ
A ± (0.15% + 10)
1.5mV/mA
500mA 10
µ
A ± (0.15% + 10)
5A 0.1mA ± (0.5% + 10)
30mV/A
10A 1mA ± (0.5% + 10)
RANGE RESOLUTION ACCURACY
500 0.01 ± (0.1% + 10)
5K 0.1 ± (0.1% + 5)
50K 1 ± (0.1% + 5)
500K 10 ± (0.1% + 5)
5M 100 ± (0.1% + 10)
50M 1K ± (0.5% + 10)
5163420K_Instructions.qxd 18/09/2009 12:57 Page 20
