6
2.2 Display Screen Icons:
8
11
12
14
1
17
7 6 5 4 3 2
16
1315
9
10
REFERENCE
NUMBER SYMBOL FUNCTION
1
°°CC °°FF
Measures unit being °C or °F of temperature
1
mmnnFF
Measures unit being µF or nF of Capacitance
1
mmµµAA
Measures unit being µA,mA or A of current
1
ddBBmmVV
Measures unit being dBm (units of power) or mV
and V (units of voltage)
1
MMKKΩΩHHzz
Measures unit being MΩ,KΩ and Ω (units of
resistance) or MHz, KHz and Hz (units of frequency)
2 Measures unit being the duty ratio of logic impulse
3
AAUUTTOO
Measures in the automatic range
4
MMAANNUUAALL
Measures in the manual range
5
5511000000
Indicator of range, indicating the full range
value of this range in manual range such as 5,
50, 500 and 1000,5000, etc.
6
MMAAXX--MMIINN
Display value being the maximum value (MAX),
the minimum value (MIN) or the maximum value
the minimum value (MAX-MIN)
7
RREELL
Measures in relative measurement mode while
displaying a relative value
8 Indicating it is now performing the continuity
measurement
9
AACC
Indicating AC measurement state is active, while
DC and AC displaying simultaneously, indicating
it is DC+AC measurement
10 Indicating the measurement value is negative
5163420K_Instructions.qxd 18/09/2009 12:56 Page 6
