Eggfinder Quick Reference Guide
Eggfinder TX (Transmitter):
Battery: 300 mAh (min.), 7.4V (2S) LiPo battery recommended
Mounting Tips:
• AVOID MOUNTING THE ANTENNA NEAR ANY METALLIC OBJECTS
• If you use the “stick” antenna, do not use a metal screw next to the antenna;
Use a nylon screw, or double-stick servo tape instead.
Operating:
Powering On:
•Press the button until the GREEN light comes on, then release
• Wait for the AMBER light to start blinking before closing up your rocket
(this means that the Eggfinder has acquired enough satellites to start sending location data)
Powering Off:
• Press the button until the GREEN light goes out, then release
• Disconnect the battery and/or turn off your power switch
Eggfinder RX (Receiver):
Serial driver: Prolific PL2303HX
Powering On: Just plug it into a USB port
Format: 9600 baud, 8 bits, no parity, 1 stop bit, no flow control (handshaking)
