Installation examples
230 V~
ZONE 3
ZONE 2
ZONE 1
230 V~
230 V~ Mains power line
ZONE 1 Loudspeaker line - Petrol pumps
ZONE 2 Loudspeaker line - Shop
ZONE 3 Loudspeaker line - Bar and office (OPTIONAL)
ZONE 3 General line BUS -S Bar and office (OPTIONAL)
10401 COMP
ACT Console
0604.02 Projectors
06050 Ceiling loudspeaker
1205 and 1204 control units
1309.1 Amplifier
1
3
2
PETROL STATION
