BASIC MAINTENANCE PROCEDURESBASIC MAINTENANCE PROCEDURES
Use the diagram below to deternrine if the sprocket(s) need to be replaced. Never use a new chain with a damaged
or worn sprocket.
THE USE OF A NEW CHAIN ON A WORN SPROCKET WILL
CAUSE RAPID CHAIN WEAR.
NOTICE
!
CHECKING BRAKE PADSCHECKING BRAKE PADS
DRIVE CHAIN ROLLERS DRIVE CHAIN ROLLERS
1. Check the bottom (B)(B) chain rollers for wear and
/ or damage. Measure the diameter of the drive
chain rollers and replace it if it is worn down,
torn or broken.
2. Check the roller bearings to make sure they are
not damaged, and they roll easily. If you feel
any resistance while turning the bearing
between your ngers, they must be replaced.
3. During installation of new rollers, clean the
threads of the roller bolt and apply Loc-Tite 243
agent to the threads.
4. Tighten the roller bolt and/or nut.
5. Make sure they are tight and will not vibrate o.
