56V CHARGER — CH7000/CH7000-FC 13
1b
Handle
Wall Mounting Hole
LED INDICATORS: Indicates the charging status. There is 4 Green LED and 1 Red/Green
biocolor LED, the latter is the one in the middle of the LEDs (Fig. 2).
2
Green LED Green LED
Red and Green biocolor LED
BATTERY-MOUNTING SLOT: Guides the battery pack when it is installed on the charger.
WALL MOUNTING HOLE: For convenient storage on the wall.
