56V CHARGER — CH7000/CH7000-FC16
LED FUNCTIONS OF CHARGER
LED INDICATOR
BATTERY
PACK
LED ON THE CHARGER POWER
INDICA-
TOR
ON THE
BATTERY
PACK
BETTRY
PACK
POWER
ACTION
LED
1#
LED
2#
LED
3#
LED
4#
LED
5#
Defective OFF OFF
Flash-
ing
RED or
OFF
OFF OFF OFF -
Battery pack
or charger is
defective
Cold/Hot
Battery
OFF OFF
Shin-
ing
RED
OFF OFF Off -
Charging will
begin when
battery pack
returns to
37°F(3°C)–
135°F (57°C)
Charging
Flashing
GREEN
OFF OFF OFF OFF
Flash-
ing RED,
ORANGE
and GREEN
alternately
or last LED
ashing
GREEN,
the former
LEDs shin-
ing solid
GREEN
<15%
Charging
Shining GREEN
alternately
OFF OFF OFF
15% to
35%
Shining GREEN alternately OFF OFF
35% to
55%
Shining GREEN alternately OFF
55% to
75%
Shining GREEN alternately ≥75%
Full
Charged
Shining GREEN continuously OFF
90% to
100%
Charging is
complete.
Maintenance
charging.
