GRASS BAGGER — ABK420010
OPERATION
When both grass baggers are full, place the Zero Turn Mower
on a rm and level surface and set the parking brake. Stop
the motors and remove the safety key to prevent unintended
starting.
1. Open the cover of grass bagger by pushing the cover handle
in rst and then lifting the cover handle (Fig. 14).
2. Remove both bagger assemblies by lifting the front edge up
rst, and then sliding the back edge forward and up until it is
clear of the frame (Fig. 15).
3. Empty the grass clippings at a proper disposal site.
4. Replace both bagger assemblies and close the cover. Restart
your mower to resume cutting your grass.
When the grass clippings are blocked in the chute tube, place
the Zero Turn Mower on a rm and level surface and set the
parking brake. Stop the motors and remove the safety key to
prevent unintended starting.
1. Stretch the rubber buckle to unlock the upper and lower
chute tube (Fig. 16).
2. Hold the tube handle to slide out the upper chute tube. Grab
the tube handle to pour out the clogged grass clippings at a
proper disposal site (Fig. 17).
3. Replace the upper chute tube assembly as shown in the Step
8 of the section “ASSEMBLY AND INSTALLATION ON THE
ZERO TURN MOWER”. Restart your mower to resume cutting
your grass.
2
1
14
1
2
15
16
Tube Handle
17
To Next Page
