MULCHING KIT — ABP52006
8. Push the deck sideways and remove it from under the mower
(Fig. 2).
9. Flip the deck on the ground so that the blades face upward.
10. Remove grass clippings, leaves, dirt, and any other
accumulated debris from the underside of the mower deck
and the fourteen holes in the deck as shown in Fig. 3.
2
Deck
Deck Hook
Blade Motor
Motor Cable
Cotter Pin
Shaft Pin
3
