56V LITHIUM-ION BACKPACK LINK — BH1001 15
REPLACE THE STRAP
1. Replace the strap with the cleaned strap or a new backpack strap.
2. Align the ribs on the new strap with the grooves on the battery mounting base to
engage them, then push down on the new strap to assemble them (Fig. 17 & 18).
3. Insert the fours buckles on the strap into the holes in the battery mounting base
to completely assemble the battery mounting base with the strap (Fig. 19 & 20).
STORAGE
1. Remove the battery pack and adaptor from the backpack link.
2. Clean all foreign material on the surface of the backpack link.
3. Fix the cable and the plug onto the hook.
4. Store in an enclosed space that is inaccessible to children. Keep away from
corrosive agents, such as garden chemicals and de-icing salts.
17 18
19 20
