How to disassemble the blower
9
Description
Part Number
Description
Part Number
Battery Release Button
3127201001
Static Dissipation Assembly
2824406001
Latch
3127202001
Anti-static Bar
3650142001
Battery Ejection Lever
3127206001
Left Handle Housing
3321366001
Speed Adjusting Knob
3127215001
Right Handle Housing
3321365001
Boost Button Level
3128066001
Handle Housing Set
2824414001
Trigger Level
3128069001
Left Housing 3321362001
PCBA
2830105001
Right Housing 3321361001
Spring 1
3660088003
Housing Set 2824413001
Spring 2
3660013003
Motor & Duct Assembly 2824335002
Spring 3
3660129002
Fan Baffle 3128068001
Rubber Gasket
5650519001
The following parts can be replaced after opening the housings.
