How to Disassemble the Blower
11
6. Use scissors to cut off the heat-shrinkable sleeves and remove the transparent sleeves
aside to separate the three connectors between the PCBA ASSY and the duct set
(motor included).
Heat-shrinkable sleeves Transparent sleeve Connectors disconnected
