39
3. Put on 3 new heat-shrinkable sleeves one by one onto each terminal, move the
transparent sleeve aside before connecting the 3 connectors and then cover the
connectors with the transparent sleeves.
Correct Connection: Brown to brown, yellow to yellow, blue to blue
How to Replace the Duct Set (Motor included)
