How to Assemble the Blower
45
2. Align the rib on the fan baffle with the limit slot in handle housing, and mount the
fan baffle into the outside groove in the left housing.
Limit slot for fan baffle rib
Rib on the Fan Baffle
Limit slot for fan baffle rib
