56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2000-S
32
PARTS LIST
No. Part Number Part Name Quantity
1 3126762000 Mulching Insert 1
2 3126785000 Side Discharge Chute 1
3 3800095000 Grass bag 1
4 3705442000 Bag Frame 1
5 2823714000 Handle-Locking Clamp Set 1
6 3126779000 Quick-Adjust Lever Cover 1
7 3127083000 Trailing Shield 1
8 3705441000 Steel Bar 1
9 5610042000 Screw Set (Trailing Shield) 4
10 3126765000 Rear Hubcap 2
11 2823663000 Rear Wheel Assembly 2
12 2823707000 Height-Adjust Handle Set 1
13 3126769000 Front Hubcap 2
14 2823662000 Front Wheel Assembly 2
15 3705369000 Blade 1
16 5650510000 Outer Flange 1
17 5640226000 Bolt 1
18 3520852000 Inner Flange 1
19 3127847000 Fan 1
20 2823706000 Bolt and Washer Set 4
21 2822802000 Key Set 1
