56V LITHIUM-ION CORDLESS BLOWER — LB6700/LB6700-FC 15
ATTACHING/REMOVING
BLOWER NOZZLE
NOTE: Only one nozzle can be
attached to the blower. The steps
below are the same for tapered and
spread nozzle.
1. Remove the battery.
2. Align the groove in the nozzle
with the knob on the tube. Push
the nozzle onto the tube until it
snaps into place (Fig. 5 & 6).
3. To remove the nozzle, press
and hold the nozzle-release
button to disengage the latch,
then pull the nozzle straight
from the blower (Fig. 7).
2
1
5
6
7
