SPECIFICATIONS
Voltage
56 V
Guide Bar Length 10” (250 mm)
Chain Pitch 1/4” (6.4 mm)
Chain Gauge 0.043” (1.1 mm)
Oil Tank Capacity 2.7 fl.oz. (80 ml)
Number of Drive Links 56
Machine Length (without extension pole)
Min. 7.6 ft (2.33 m)
Max. 9.6 ft (2.92 m)
Machine Length (with 1 extension pole)
Min. 10.9 ft (3.33 m)
Max. 12.9 ft (3.92 m)
Machine Length (with 2 extension poles at
most)
Min. 14.2 ft (4.33 m)
Max. 16.2 ft (4.92 m)
Recommended Operating Temperature 5°F – 104°F (-15°C – 40°C)
Recommended Storage Temperature -4°F – 158°F (-20°C – 70°C)
Weight (without battery pack and chain sheath) 9.5 lb (4.3 kg)
Ingress Protection (IP) Rating IPX5* (Protection against water jets).
* NOTE: IPX5 rating is based on the machine and battery being used together as a
system.
RECOMMENDED ACCESSORIES
PART NAME MODEL NUMBER
Guide Bar AG1000Q
Saw Chain AC1000Q
Extension Pole EP1000
Shoulder Strap AP1500
56-VOLT LITHIUM-ION COMMERICAL POLE SAW — PSX2510/PSX2510-FC12
