External filter 2211
Function
A
Pump head
filter canister
pressure side hose connection
suction side hose connection
lattice screen
suction pipe
strainer
suction cups with clips
outlet elbow
outlet
pipe
base.
B Rinse all filter media under running water and insert them into the
filter canister according to the drawing: coarse filter pad blue,
EHEIM SUBSTRATpro or SUBSTRAT, and fine filter pad
white.
Installation
C Put on the pump head and examine the o-ring for correct fitting.
Close the clips.
D Place filter underneath aquarium – it must be below water level.
E/F Fit outlet pipe as per drawing A or B.
G Assemble suction pipe and strainer and attach to side of aquarium
with 2 suction cups and fit hose connections to filter: suction side
on bottom intake nozzle, pressure side on pump head.
Fasten hoses with clamping nut (drawing K).
b
c
a
Putting into operation
There are 3 ways to prime the filter. 1) With the starter bulb (order
no. 4003540), 2) with the Universal Installation Kit 1 (see G1,
order no. 4004300) or 3) by sucking the hose on the pressure
side.
Connect the pressure side hose to the outlet elbow and the spray
bar while the filter fills with water. The pump can be switched on
when water has filled the filter, and for a short time while trapped
air is exhausted from the filter media a slight noise from the pump
will be heard (this is normal).
Fit the plug into the end of the spray bar after all the air bubbles
have disappeared.
Servicing and maintenance
H/I Pull out mains plug. Release locking piece on pump head and
remove pump parts as per drawing. Lift out cooling channel insert
(drawing I) with screwdriver. Clean all parts and then reassemble
in the reverse order.
Note:
All hose connections must be checked at regular intervals for cor-
rect fitting.
Attention:
The impeller blades must rotate free on the impeller, and the impel-
ler must spin freely on the ceramic shaft, so that the pump starts
without trouble.
