External filter 2426
햲
Pump head
햳
Sealing gasket
햴
Input connector
햵
Lattice screen
햶
Fine filter pad (white)
햷
Coarse foam filter
pad (blue)
햸
Rubber hermetic seals
햹
Filter media con-
tainers
햺
EZ clips
햻
Filter canister
햽
Integrated double
tap connector
햾
Hose clamp
햿
Intake pipe
헀
Intake
strainer
헁
Security outlet pipe
헂
Spray bar and end cap
헃
Suction cups with clips
헄
Tubing
헅
Vaseline.
When unpacking, please check to ensure that all parts have
been included.
Assembly
Flip all four EZ clips open and push upwards. With the help
of the two recessed lid handles, the pump head of the filter
can be easily lifted off.
↕
Do not overfill. Do not clog flow-through pipe.
7
Insert the second media container in the same manner.
Make sure the flow-through pipe openings line up on top of
each other. Put second rubber hermetic seals on the upper
media container. Lower each retractable handle and ensure
that all media containers lie flush on top of each other.
Then insert the fine filter pad (white) and the lattice screen in
such a manner that the round cut-out lines up with the re-
spective flow-through pipe opening.
The lower filter tank is to
be filled with EHEIM filter
pads.
Fill the second container
with the biological media
SUBSTRAT to just below
the edge.
ATTENTION: Fine filter pad (white) should not be placed
under the retractable handle of the media container.
Fill the first container with EHEIM filter pads, but leave just
enough space so that the blue filter pad can be placed in
the container under the retractable handle. Fill the second
container with the biological media SUBSTRAT to just below
the edge.
Then thoroughly rinse the filter media in the containers
under running water until all cloudiness has disappeared.
Remove lattice screen and fine filter pad and take out each
media container by grabbing the retractable handles and
pulling upwards. Fill the containers with EHEIM filter media
to achieve best results.
GB
