9. J)
Fig. 2. Strip back the outer
insulation 1 1/2" from one
end of a 10"
piece of 3 conductor shielded cable. Twist
the shield strands together and
cover with a 1 1/4" piece of thick spaghetti. Cut the
brown lead to
1 1/4"
the red lead to 3/4" and the orange lead to I"
. Strip
back the insulation 1/4"
from the end of each of these leads.
Connect the brown lead to SlB-6 (S2),
the red lead to S
1 B-8 (S 1), the orange lead to S 18-9 (S 1) and the twisted
shield strands to S lA-
10 (C). On the other end of the same piece of shielded
cable, strip the outer insulation back 3/4"
. Twist the shield strands together.
Strip
k the in,ulaHon 1/4" fwm the end af each af the inne, conduct"".
This en
of the cable does not get connected unti I later.
10.
iJ IF; g.
2. Connect one end of 0 3 1/2" piece of block wi 'e to
5 IA - 10 (52).
11. (
Fig. 2. Strip back the outer insulation
1 3/4" from one end of a l0"
piece of the4 conductor shielded cable. Twist the shield
strands together and
cover with a 1 1/2" piece of thick spaghetti Cut the
brown, red and orange
leads to 3/4" each and the yellow lead to
1 1/4" Strip back the insulation
1/4" from the end of each of thes~ leads.
Connect the
brown lead to SlD-
(SI),
the red lead toS1D-
9(Sl), the orange lead toSlD-
10(S1)and the yello
lead- to S 10- 11 (C).
Connect a 1" piece
of bare wire from S ID- l1 (S2) to S 1 E-
(S 1). Connect
the twisted shield strands' to S lC-
6 (C). On the other end of the
U'I same piece of shield cable, strip the outer insulation
back 1 1/4". Twist the
shield strands. Cut the red, orange
, and yellow leads to 1" . Cut the
shield
strands to 3/4". Strip back the insu lation 1/4" from the end of each of the
inner
conductc?rs. This end of the cable does not get connected until
later.
12.
N.)
Fig. 2.
Strip back the insulation 1 3/4" from
one end of a 9 1/2"
piece of 3 conductor shield cable. Twist the shield
strands together and cover
wIth a 1 1/2" piece of thick spaghetti. Cut the
brown and red leads to 3/4"
and the orange lead to 1"
. Strip
back the insulatIon 1/4" from the end of
each
of these leads. Connect the orange lead to
S 1 F- 12 (S 1), the red lead to S 1 F- l 0
(Sl), the brown lead to SlF-9(Sl) and the twisted shield strands to SlF-
6 (C).
On the other end of the same piece of shielded cable, strip the outer insulation
back 1 1/4"
. Twist the shield strands. Cut the
shield strands, red lead and
oran~e lead to 3/4" and the brown lead to 1"
. Strip back the insulation 1/4"
from f~e e
?d of each of the inner conductors. This end of the cable does not
get co~neqted until later.
13. ~~F!~ 2. Connect one end
of a 4 1/2" piece of black wire to SlF-6(C).
, /i
V I
14
(V)\.Fi
S 1 F-6 (Si3)
2. Connect a
1 1/2" piece of bare wire from SlC-
6 (S2) to
15. (,)
Fig. 2. Strip back the outer
insulation 1 1/4" from one end of a
7 1/2" piece of 3 conductor shield cable.
Twist the shield strands together,
and cover with a 1" piece of thick spaghetti. Cut the orange
and red leads to
3/4" and the brown lead to 1"
. Strip the insulation
back 1/4" from this end of
each of these leads. Connect the orange lead to S IH-I0 (S
1), the red lead to
SlH-9(S1), the brown lead to SlH-
7(S2)and the shield strands toS1H-
ll (C).
On the other end of the same piece of shielded cable, strip the outer Insulation
back 3/4"
. Twht the
shield strands together. Strip back the insulation 1/4"
from the end 9feuch of the inner
conductors. This end of the cable does not
get conne ~'d unti
I later.
16. ~.
. ~
rg.
2. Connect one end of
a 2" piece of black wire to S
1 H- l1 (S2).
17.
td
Fig. 2.
- Connect one end of a 2 1/2"
piece of grey wire to S 18-
11 (S 1).
18. V) Fig. 2. On one end of a 4 1/2" piece of single
conductor shielded
cable, strip the outer insulating back 1/2"
. Twist the shield strands together
and cut off:
Strip back the inner insulation 1/4" and connect to S18-
5 (Sl).
On the other end of the same piece of shielded cable, strip back the outer in-
sulation3/4"
; Twist the shield strands together. Strip
back the inner insulation
1/4"
. Jhis end of the cable does not get
connected until later.
19.
(v)
fig. 2. Connectoneendofa5"
pieceofbrownwiretoS1D-
7(S1).
20. (
'Fig.
2. Connect one end of a
3" piece of brown wire to SlF-
8 (SI).
21. (
I,
Fig. 2. On one of a 4" piece of
single conductor shielded cable,
strip the outer insulated back 1/2"
. Twist the shield strands together and cut
off. Strip back the inner insulation 1/4" and connect to SlG-6(Sl).
On the
other end of the same piece of cable,
strip the outer insulation back 3/4"
Twist the shield strands together.
Strip back the inner insulation 1/4"
. This
end of t~e cable does not get connected until later.
22. (
/)
Fig. 2.
Connect one end of a 3" piece of grey wire to S 1 G-
12 (S 1).
23. (~/Fig.
2. Connect
one end of a 5" piece of grey wire to SlD-
3 (Sl)
and one end of a 5" piece of yellow wire to SlE-
4 (Sl). Twist
the two leads
together. .
24. (
v) Fig. 2. Connect one end of a 4 1/2" piece of
green wire to S 1C-2 (S 1)
and one end of a 4 1/2"
piece of blue wire to S lC-4 (S2). Twist the two
leads tog/
ether.
25 (
vfFi9. 2. Connect one end of
a 5 1/2" piece of brown wire to
S 1 E-
3 (S 1)
and one end of a 5 1/2" piece of white wire to SlF-
5 (S2). Twist the two
leads together.
