HQ Series I&M Manual HQ-400-1005 11

HQ Standard Features

Enclosure Rated Weatherproof IP67, NEMA 4 & 6

Enclosure High grade aluminum alloy, corrosion coated

Power Supply 110/220VAC 1 PH 50/60Hz, 440VAC 3PH 50/60Hz

Duty Cycle EC 34 S2 (25~30%)

Motor Squirrel caged induction motor

Limit Switches 2 x open/close SPDT, 250VAC 10A rating

Auxiliary Limit Switches 2 x open/close SPDT, 250VAC 10A rating (except HQ008)

Torque Switches Open/close SPDT, 250VAC 10A Rating (except HQ008)

Stall Protection Built –in thermal protection

Travel Angle 90 degree +/- 10%

Indicator Continuous position indicator

Manual Override Declutchable manual override

Self Locking By means of worm gear

Mechanical Travel Stops 2 x external adjustable mechanical travel stops

Space Heater 7~10W ceramic housed

Conduit Entries 2 x PF3/4”

Lubrication Grease moly EP

Ambient Temperature -20 deg C ~ + 70 dec C (except on CPT & PCU board )

External Coating Dry powder polyester, Munsell No. 5R 3.5/12
