HQ Series I&M Manual HQ-400-1005 9
15.0 MDPI Settings
 Manually rotate actuator to fully closed position
 Remove actuator cover
 Loosen indicator screw
 Adjust indicator to correct orientation
 Tighten indicator screw
 Replace cover
 Check indicator alignment
16.0 Maintenance
At least once a year a check should be make of your EIM HQ Series Actuator
 Disconnect all power to actuator.
 Open Electrical Enclosure. Inspect and tighten all electrical connections
 Visually inspect for any electrical or mechanical damage. Replace worn or damaged components.
 Check lubrication consistency and levels. Fill or replace if required.
17.0 Storage
Actuators must be stored in a clean, cool and dry area. The unit shall be stored with the cover installed
and the conduit openings sealed. Storage must be off the floor, covered with a sealed dust protector.
