GB
4
Scope of delivery package
BSM 710 E,
Quick-change drill chuck 2 -13 mm,
Additional grip with bit stop
Description
1 Quick-change drill chuck
2 Depth stop
3 Additional handle
4 Selector button: drill/hammer
5 Selector button:
clockwise/anticlockwise
6 Speed control
7 Locking button
8 On/Off switch
Technical data
Voltage: 230 V ~ 50 Hz
Power rating: 710 W
Drilling capacity Concrete 13 mm
Steel 10 mm
Wood 20 mm
No Load Speed 0 - 2.400 min
-1
Number of blows 0 - 38.400 min
Safety insulated II /
Sound pressure
level LPA 89,2 dB(A)
Sound power
level LWA 102,2 dB(A)
Vibration a
w
5,6 m/s
2
Weight 2,2 kg
Caution
The BSM 710 E is not desi-
gned for the operating of auxili-
ary devices.
Do not use near steams or
inflammable liquids.
Only use sharp bits and suita-
ble screwing bits.
Remove the plug from the
socket for all adjusting and
cleaning work.
Protect the mains cable against
any damage. Oil and acids can
damage the cable.
Do not carry the device by the
mains cable.
Do not remove the plug from
the socket by pulling the mains
cable.
Make sure before inserting the
plug that the operating switch is
not locked.
When using a cable drum
uncoil the cable completely.
Cross-section of wire at least
1,5 mm
2
.
Do not overload machine.
Secure all workpieces to be
processed sufficiently.
Do not allow children to have
access.
Make sure you have a secure
stance on ladders or scaffold-
ing when using the drill free-
hand.
Localise lines with a line detec-
