8
TECHNICAL DATA
Nominal voltage: 230 V ~ 50 Hz
Power consumption: 710 W
Cutting rate: 0-2800 strokes/min.
Stroke height: 19 mm
Cutting depth in wood: 80 mm
Cutting depth in plastic: 20 mm
Cutting depth in iron: 12 mm
Mitre cuts: up to 45° (left and right)
Sound pressure level LPA: 94 dB(A)
Sound power level LWA: 107 dB(A)
Vibration a
w
5,71 m/s
2
Double isolation II /
Weight 2,5 Kg
Laser class 2
Laser wave length 650 nm
Laser output ≤ 1 mW
Laser module power supply
2 x 1,5 V button cell battery
Ordering replacement parts
Please quote the following data when ordering repla-
cement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
Replacement part Replacement part number
Carbon brush 44.720.40.01.001
Switch 44.720.40.01.002
GB
