Einhell Global SHZ 300-2 - Technical Data

GB
16
4. Technical data
SHZ 300-2 SHZ 500-2 SHZ 600
Without With Without With Without With
return return return return return return
pulley pulley pulley pulley pulley pulley
Loading capacity 150 kg 300 kg 250 kg 500 kg 300 kg 600 kg
Max. lifting height 11,5 m 5,7 m 11,5 m 5,7 m 11,5 m 5,7 m
Average 10 m/min. 5 m/min. 10 m/min. 5 m/min. 10 m/min. 5 m/min.
lifting speed
Cable length 12 m 12 m 12 m
Non self-turning 3,05 mm 4,2 mm 4,5 mm
steel cable CK 45 Ø
Cable breaking limit 1200 kg 2000 kg 2400 kg
Electric motor:
Line voltage 230 V - 50 Hz 230 V - 50 Hz 230 V - 50 Hz
Power P
1
550 W P
1
900 W P
1
1050 W
Protection type IP 54 IP 54 IP 54
Insulation class KL <B> KL <B> KL <B>
Intermittent periodic
duty S3 20% - 10 min. S3 25% - 10 min. S3 20% - 10 min.
Engine class 1 EM 1 EM 1 EM
