Accessories
11 Exhaust air connection fittings
12 Bushing ring
13 Exhaust air hose
14 Foam material (Used for exhaust air outlet
through the window.)
15 Foam material (Used for exhaust air outlet
through the open window and placed in the open
section of the window. As far as possible, no
additional warm air should come into the room
from outside.)
16 Cap for the hole in the window/wall
18 Drainage water hose
19 Activated carbon filter
Remote control
Description of the operating elements
1. LED “Automatic mode set”
2. LED “Cool mode set”
3. LED “Fan mode set”
4. Not assigned
5. LED “Fan: Slow”
6. LED “Fan: Medium”
7. LED “Fan: Fast”
8. LED “Timer actuated”
9. LED “Room temperature”
10. LED “Condensation water tank full”
11. LED “Set temperature”
12. LED “Sleep function set”
13. Not assigned
14. Not assigned
15. “Sleep function” selector
16. “Warmer” selector
17. “Cooler” selector
18. LCD indicator panel
19. ON/OFF switch
20. “Timer” switch
21. “Fan speed” selector
22. “Mode” selector
23. Remote control sensor
Switching the device on and off
Press the On/Off switch. The device starts up
automatically. If the ambient temperature:
앬 is higher than 23°C the device will run in cooling
mode;
앬 if it is between 20°C and 23°C the device will run
in fan mode.
The status of the device, or mode in which it is
running, will be shown by the corresponding LEDs
(see indicator panel).
Note: The LCD indicator panel shows the current
room temperature (0 -50°C).
To switch the device off, press the On/Off switch
again.
Selecting the mode
Press the “Mode” selector (MODE) in the sequence
“Automatic”, “Cool”, “Fan”. The LED for the selected
mode lights up (see indicator panel).
12
GB
22
21
20
19
18
17
16
15
14
13
12
11
10
9
23
8
7
6
5
4
3
2
1
