1. Empty the petrol tank with a petrol suction pump.
2. Start the engine and let it run until any remaining
petrol has been used up.
3. Change the oil at the end of every season. To do
so, remove the used engine oil from a warm
engine and refill with fresh oil (see Changing the
oil, item 12/4).
4. Remove the spark plug from the cylinder head.
Fill the cylinder with approx. 20 ml of oil from an
oil can. Slowly pull back the starter handle, which
will bathe the cylinder wall with oil. Screw the
spark plug back in.
5. Clean the cooling fins of the cylinder and the
housing.
6. Be sure to clean the entire machine to protect
the paint.
7. Store the machine in a well-ventilated place.
14. Preparing the mower for
transportation
1. Empty the petrol tank (see item 13/1).
2. Always let the engine run until it has used up the
remainder of petrol in the tank.
3. Empty the engine oil from the warm engine.
4. Remove the spark plug boot from the spark plug.
5. Clean the cooling fins of the cylinder and the
housing.
6. Remove the start tension cable from the hook
(Fig. 7). Slacken the wing nuts and fold down the
upper push bar (Fig. 4-5).
7. Wedge a few layers of corrugated cardboard
between the upper and lower push bars and the
engine in order to prevent any chafing.
15. Technical data
Engine type:
Single cylinder four-stroke engine, 135 ccm
Engine power: 2.75 kW/3.75 HP
Working speed: approx. 3100 min
-1
Fuel: Lead-free standard petrol
Tank capacity: approx. 1.3 l
Petrol filling level: approx. 1.1 l
Engine oil: approx. 0.6 l / 15W40
Spark plug: F6 TC
Electrode spacing: 0.5 – 0.6 mm
Cutting height adjustment:
central, 5 levels (32-70 mm)
Cutting width: 460 mm
L
pA
sound pressure level: 76 dB(A)
L
WA
sound power level: 96 dB(A)
Vibration a
hw
2.56 m/s
2
Weight: 35,5 kg
16. Ordering replacement parts
Please quote the following data when ordering
replacement parts:
앬 Type of machine
앬 Article number of the machine
앬 Identification number of the machine
앬 Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
