Komponenten / Ersatzteile
Position Artikel-Nr. Beschreibung
Position Artikel-Nr. Beschreibung
1 343054201001 feeding barrel
4 343054201004 Feeding inlet
6 343054201006 Capacitor 45æF
14 343054201014 2nd pin shaft
15 343054201015 Bushing
16 343054201016 Blade frame
17 343054201017 Bushing
18 343054201018 Hex Screw M6 x 30
19 343054201019 Spring Washer
20 343054201020 Adjusted Knob
22 343054201022 self-locked nut M10
23 343054201023 Baffle
24 343054201024 Blade
42 343054201042 Safety cover
46 343054201046 Grass box
47 343054201047 key
48 343054201048 screw M4 x 10
49 343054201049 Switch handle
50 343054201050 handle cover
51 343054201051 Screw 4,2 x 10
58 343054201058 Wheel Cover B
59 343054201059 Wheel
60 343054201060 Bushing
61 343054201061 Flat Washer
62 343054201062 Hex Screw M8 x 85
63 343054201063 self-locked nut M8
74 343054201074 Fixed Base
81 343054201081 Tripping switch
82 343054201082 screw 4,2 x 10
83 343054201083 Safety cover
84 343054201084 screw 4,2 x 10
92 343054201092 Fan
94 343054201094 Switch box
95 343054201095 socket
98 343054201098 reverse running switch
99 343054201099 Over-current Protector
100 343054201100 on/off switch KJD17 A.18A
103 343054201103 Switch cover
901 343054201901 under frame
902 343054201902 foot assy incl. Befestigungsschraube
903 343054201903 cover cpl.
904 343054201904 axle cpl mit Passfeder
905 343054201905 planetary gear
906 343054201906 rotor cpl
907 343054201907 Gear housing komplett
0 343054201104 tool set
0 343054201105 washer für Pos. 45
0 343054201106 metal plate
0 343054201107 plastic plate
0 343054201108 plate
0 343054201109 O-Ring
0 343054201110 screw M6 x 25
0 343054201111 circlip für Lüfterrad
0 343054201112 sealing
